Well Pump Start Capacitor

Volume: 86-103 mfd

Fit for Franklin 3/4 and 1 HP Control Box 2801074915, CRC 2824085015 and other similar water pump control boxes

Overview Size: 3.0″ height x 2.0″ diameter

Net Weight: 2 oz

Common Remarks:

1.Not worry about this round capacitor installing, most are fixed with nylon ties or press-fixed with one bent steel pin

2.There are 1 start capacitor and 1 run capacitor together inside well pump control box

3.Normaly well pump run capacitor is CBB60(plastic shell) capacitor or CBB65(Aluminium Shell) capacitor,advise to use CBB65 capacitor for better heat dissipation and stability

Well Pump Start Capacitor

Volume: 59-71 mfd

Fit for Franklin 1/2HP and 3/4HP Control Box 2801054915, CRC 2824075015 and other similar water pump control boxes

Overview Size: 3.0″ height x 2.0″ diameter

Net Weight: 2 oz

Common Remarks:

1.Not worry about this round capacitor installing, most are fixed with nylon ties or press-fixed with one bent steel pin

2.There are 1 start capacitor and 1 run capacitor together inside well pump control box

3.Normaly well pump run capacitor is CBB60(plastic shell) capacitor or CBB65(Aluminium Shell) capacitor,advise to use CBB65 capacitor for better heat dissipation and stability

THIS IS A BRAND NEW IN THE BOX SQUARE D DEFINITE PURPOSE MAGNETIC MOTOR STARTER W/ THERMAL OVERLOAD/HEATER. A magnetic starter is an electromagnetically operated switch which provides a safe method for starting an electric motor with a large load. Magnetic starters also provide under-voltage and overload protection and an automatic cutoff in the event of a power failure. 5HP SINGLE PHASE 30AMP 208-240VAC 8911DPSG32V09 OR 8911DPSO32V09 IF READING DIRECTLY OFF THE CONTACTOR HORSEPOWER: 5 PHASE: SINGLE (2 POLE) VOLTAGE: 208-240VAC ENCLOSURE: NEMA SIZE 1 AMP RATING: 30 CONTACTOR THERMAL OVERLOAD/HEATER: 5HP THERMAL OVERLOAD INCLUDED THE COIL VOLTAGE RANGE IS 208-240 VOLTS AND THE STARTER CAN BE USED FOR 1-5 HP APPLICATIONS. BARRING THE CORRECT HEATER SIZE. MESSAGE US IF YOUR APPLICATION IS LESS THAN 5HP SO WE CAN EQUIP YOU WITH THE CORRECT THERMAL OVERLOAD

A capacitor is an electric component that temporarily stores an electrical charge. A dual “run capacitor” supports two electric motors, such as a fan motor and a compressor. Round dual run capacitors are used to start and run the unit more efficient. It saves space by combining two physical capacitors into one case. The dual capacitor has three terminals labeled “C”, “FAN”, and “HERM”, which stand for the *C*ommon, Fan, and *HERM*etically sealed compressor.

Dual capacitors come in a variety of sizes, depending on the capacitance (µF = MFD = micro farad), such as 60 plus 5 µF, and also the voltage. A 440 volt capacitor can be used in place of a 370 volt, as it is build better, but the 370 can’t be used in place of a 440 volt. It will work for a while and will fail prematurely, as exceeding the capacitor’s rated voltage will cause the dielectric to break down and the capacitor to short out. Same as an electric wire- 600V rated wire is better than 300V one .The capacitance(µF or MFD or micro farad) must be the same or stay within 10%+ or 5%- of its original value . Example: 60 µF cap can be substituted by 33 – 38 MFD with the same or better voltage ratings capacitor.

If your fan is working but compressor not, or the capacitor is bulged on top most likely your capacitor is defective. Round capacitor can be used to substitute oval shape one with the same MFD AND Volt specs.

You will ask “Why I need a Cap that is rated 440V in my A/C?”

Answer: You need to realize that a motor is an inductive device. When the supply voltage is applied to the motor run winding, the voltage across the start winding will be increased to a higher voltage value. A motor acts like a transformer with the run winding acting as the primary and the start winding acting as the secondary. This is why the capacitor has a much higher voltage rating than the 230 being the supply voltage.

If a Capacitor is not EIA-456-A approved means it is NOT approved for USA market.
